Servo geared motors



MCS synchronous servo motors

  • When strict requirements are placed on dynamics and precision with small sizes, the synchronous MCS servo motors are the right choice.
  • The stator winding of the MCS motors is made up of individual coils using innovative Single Element Pole Technology– SEpT for short. High-quality magnetic materials and specially developed pole forms create the prerequisites for the excellent drive properties.

MCA Asynchronous servo motors

  • Application-oriented design, low moments of inertia, a compact size and high intrinsic operational reliability make these robust and dynamic motors stand out.
  • When an application requires a broad range of speeds and a robust design, the decision is easy, MCA asynchronous servo motors are the right choice.

Lenze gearboxes & geared motors

  • Compact:

       The modular concept and the high power density due to ground gears with optimized gear profiles make         extremely compact designs possible.

  • Quiet:

       The optimum teeth geometry reduces the generation of noise.

  • Carefully stepped output speeds:

       The wide ratio range of the gearboxes combined with the small ratio step

       n = 1.12 enables the required output speed range to be selected with precision.

  • Drive controller compatibility:

    The double-coated wire winding with additional phase insulation provides extremely high dielectric strength     and has excellent mechanical resistance.

  • Reduced backlash:

     The two-stage basic concept (helical-bevel gearboxes are three-stage), connecting elements with reduced      play and the high quality of the toothing due to precision manufacturing results in reduced output backlash      in comparison with similar geared motors.

Gearbox types:

  • Helical gearboxes.
  • Shaft mounted helical gearboxes.
  • Bevel gearboxes.
  • Helical bevel gearboxes.
  • Helical worm gearboxes.
  • Planetary gearboxes.


Ratings:

  • Powers:
    • MCA motors: 0.8-45.5 KW, 400VAC.
    • MCS motors: 0.25-15.8 KW, 230 or 400VAC.

Torques and reduction ratios:

  • Helical gearboxes:
  1. Power: up to 45 KW.
  2. Torque: up to 6000 Nm.
  3. Reduction ratios: up to 1: 400.
  • Shaft mounted helical gearboxes:
  1. Power: up to 45 KW.
  2. Torque: up to 11300 Nm.
  3. Reduction ratios: up to 1: 800.
  • Bevel gearboxes:
  1. Power: up to 7.5 KW.
  2. Torque: up to 450 Nm.
  3. Reduction ratios: up to 1:69.
  • Helical bevel gearboxes:
  1. Power: up to 45 KW.
  2. Torque: up to 11800 Nm.
  3. Reduction ratios: up to 1:1400.
  • Helical worm gearboxes:
  1. Power: up to 15 KW.
  2. Torque: up to 1250 Nm.
  3. Reduction ratios: up to 1:1800.
  • Planetary gearboxes:
  1. Power: up to 7.5 KW.
  2. Torque: up to 390 Nm.
  3. Reduction ratios: up to 1:100.
