 The intelligent drive for modular machines, power range: 0.37 to 75 kW

• Peak current: up 150% for 60s, 200% for 3s.
• Control modes: Field-oriented servo control (SC)
• Applications: Speed/phase synchronism, Table positioning, Curve profiles, and Register control.
• Monitoring/protections: Motor overload/over temperature, I² x t-monitoring, Short circuit, Short to earth, overvoltage, under voltage.
• Connections: start/stop, analog inputs/outputs (2/2), freely programmable digital inputs/outputs (5/4).
• Feedback: Resolver and multi-encoder input.
• Communication: (integrated) CANbus, (optional) Lecom-A/B/LI, DeviceNet, CANopen, Interbus,        Profibus, AS-i.
• Versions:
1. 9300 Servo Inverter EVS93xx-ES
2. 9300 Servo Position Controller EVS93xx-EP
3. 9300 Servo CAM Controller EVS93xx-EK
4. 9300 Servo Register Controller EVS93xx-ER
