For maximum efficiency

Our bevel gearboxes are a showpiece for lightweight engineering. They are also highly efficient and feature wear-free toothing.

In combination with three-phase AC and servo motors, bevel gearboxes form an effici ent, compact drive unit. They are available in a 2-stage design with a torque of up to 3983 in-lbs (450 Nm) and a ratio of up to i=76.

Our designs for you:

• 2-stage gearbox
• Hollow-shaft with keyway or shr ink disc
• Solid-shaft with keyway
• Foot or flange mounting
• Torque plate, including rubber buffer

Can be combined with the following motors:

• With three-phase AC motors in line with the ErP Directive in the power range from 0.08 Hp to 10 Hp (0.06 to 7.5 kW)
• With servo motors in the power range from 0.33 to 9.5 Hp (0.25 to 7 kW)
• Drive Package versions in conjunction with the decentralized Inverter Drives 8400 motec cover a power range of up to 10 Hp (7.5 kW)
